This is a short-range detector that detects an object in its range by picking a reflected InfraRed signal generated by the on-board IR transmitter. An adjustable 0-10 second timer adds functionality by maintaining a contact for external controls. The same circuit may be used with photo interrupters and mark-sense reflective detectors in materials handling applications.

Technical Specification

  • Power Supply : 12V @ 100mA
  • Detection Range : 5-30cm
  • Time Delay : 0-10sec.
  • Relay Contact Load : 10A @ 110VAC,5A @ 230VAC
  • PCB Dimensions : 3.84" x 2.01" x 0.8" (97.5mm 51mm x 20mm)
